Wavecor WF182CU12 17 cm bass midrange glass fibre
Wavecor WF182CU12 17 cm bass midrange glass fibre

Wavecor WF182CU12 17 cm bass midrange glass fibre

Out-of-Stock
€217.55 €229.00 -5%

Tax included
rating No review at the moment

Wavecor WF182CU12 17 cm bass midrange glass fibre

  • power handling (continuous/programme) = 100 W
  • frequency range = 35-3000 Hz
  • resonance frequency fs = 33 Hz
  • impedance R = 8 Ohm
  • sound pressure level SPL = 87,2 dB


Estimated Shipping Costs
Shipping Costs
€16.80
Shipping Time
.
Want to check another country or courier?



Specifications

power handling (continuous/programme) = 100 W

frequency range = 35-3000 Hz

resonance frequency fs = 33 Hz

impedance R = 8 Ohm

sound pressure level SPL = 87,2 dB (2,83V; 1m)

DC resistance Re = 6,4 Ohm

force factor BL = 8,2 N/A

effective piston radiating area Sd = 131 cm2

effective mechanical mass incl. air load mms = 19,5 g

equivalent volume of compliance Vas = 29 l

total Q factor Qts = 0,37 (Qms=9,2, Qes=0,39)

voice coil diameter = 39 mm

maximum peak linear excursion vibration xlin = +/- 5,5 mm

mounting diameter d = 153 mm

overall diameter d = 182 mm

mounting depth (not countersunk) t = 88 mm

WF182CU12
