Cerwin-Vega HED H800.4D Class D 4-channel amplifier

Universal HED series, Class D 4-channel amplifier from Cerwin-Vega®. This Cerwin-Vega® power amplifier is designed to drive even the most inefficient speakers and/or subwoofers, pushing their performance to the highest level of distortion-free sound. The product is of the highest possible quality to provide many years of worry-free ownership. Our High Energy Design power stages generate even more power compared to previous generation HED models.

.

Technical data

Number of channels 4

Amplifier class D

Power in 2 ohms RMS 4x200W

Power in 4 ohm bridged RMS 2x400W

Power in 4 ohms RMS 4x120W

Frequency range 10Hz-45KHz

High pass filter 15-350Hz

Low pass filter 35-350Hz

Bass boost Yes

Bass remote / remote control No

Attenuation factor >70

Input impedance 20KΩ

Input sensitivity 0.15-12V

Recommended power and ground cable 25mm2

Signal noise 101.1dBa

Fuses 2x30A

THD 0.1%

Dimensions 345x178x52mm
