DD Audio SA300.4 is mini chassis amp designed to make space constrained installations a breeze.

SHIPMENT IN 7/10 WORKING DAYS
€179.00
Tax included
rating Read the review
Average rating: 10/10 Number of reviews: 1

Estimated Shipping Costs
Shipping Costs
€16.80
Shipping Time
.
Want to check another country or courier?



DD Audio SA300.4 Amplifier 4 channels class D

.

DD Audio SA300.4 is mini chassis amp designed to make space constrained installations a breeze. Don’t be fooled by its small stature in 4 ohm bridged mode this little powerhouse can produce over 2 x 120Watts - Great sound quality - Mosfet power supply amplifier - 4 gauge set screw power terminals - 12 gauge set screw speaker terminals - Variable 12dB/oct crossovers - Remote subwoofer control (SA500.1) - 5-way protection: Speaker short, thermal, overload, HI/LOW voltage, DC offset

.

Technical Specifications

  • Mosfet power supply amplifier
  • 4 gauge set screw power terminals
  • 12 gauge set screw speaker terminals
  • Variable 12dB/oct crossovers
  • Remote subwoofer control (SA500.1)
  • 5-way protection: Speaker short, thermal, overload, HI/LOW voltage, DC offset
  • Operating voltage: 9-16
  • Test voltage: 14.4
  • Output Channels: 4¨
  • Cont wattage @4Ohm: 4x65 / 2x120
  • Cont wattage @2Ohm: 4x75
  • Cont wattage @1Ohm: NA
  • Dynamic wattage: 600
  • Max current draw - Amps: 30
  • RCA input sensivity - Volts: 6 - 0.25
  • High level sensivity - Volts: 20 - 1.1
  • Frequency response - Hz: 85
  • S/N Ratio -dB: 70
  • Damping factor: 10 - 3000
  • THD: 0.1%
  • Boost level: NA
  • High pass filter - Hz: 35 - 250
  • Subsonic filter - Hz: 35 -250
  • Low pass filter - Hz: NA
  • Remote subwoofer control: NA
  • Power wire gauge - IN: 4
  • Speaker wire gauge - OUT: 12
  • Dimensions - in 7 x 3.8 x 1.69
  • Dimensions - mm 180 x 96 x 43

SA300.4
2 Items
DDAUDIO AMPLIFIER
rating
06/06/2022
Jack T.
Cheap and really compact. Performance are super for this price. If you need compact amplifier 4 channel with good quality without pay a lot, this is one of the best choice.
