Edge Audio EDX800.4FD-E0 4 Channel Full Range Class D Amplifier

Edge Audio EDX800.4FD-E0 4 Channel Full Range Class D Amplifier

Name: Edge Audio EDX800.4FD-E0 4 Channel Full Range Class D Amplifier
Brand: Edge Audio
SKU: Edge Audio EDX800.4FD-E0
Price: 459 EUR
Availability: InStock

Edge Audio EDX800.4FD-E0 4 Channel Full Range Class D Amplifier

EDGE is a Brand of the VIBE Car Audio GROUP. Innovative Car Audio Products with an unbeatable Quality/Price Ratio and exciting Performances! Speakers, Subwoofers, Amplifiers and Accessories Made with the aim of not excluding anyone from the glittering world of car audio.

SHIPMENT IN 7/10 WORKING DAYS

€459.00

Tax included

No review at the moment

Estimated Shipping Costs

Shipping Costs

€21.60

Shipping Time

Want to check another country or courier?

Edge Audio EDX800.4FD-E0 4 Channel Full Range Class D Amplifier

EDGE is a Brand of the VIBE Car Audio GROUP.

Innovative Car Audio Products with an unbeatable Quality/Price Ratio and exciting Performances! Speakers, Subwoofers, Amplifiers and Accessories Made with the aim of not excluding anyone from the glittering world of car audio.

The XTREME amplifiers are a New addition to the EDGE range, these amplifiers feature a Class D topology but use a full bridge method of power delivery.

This is the most efficient method of converting DC power from the battery to AC output for the speakers. Full bridge technology allows us to generate a lot of power in a small footprint. The custom machined heat sink has been designed with over-engineered fins for excellent heat dissection ensuring the amplifier runs well and cools properly.

All models feature active crossovers and bass boost and can be used to power subwoofers, midrange drivers or tweeters.

Compact and powerful, the perfect amplifier upgrade for those who want a little more than the norm.

Technical Specifications:

4 Channel Class D Amplifier
Output power on 4 x 800 watt rms 1 ohm
4 x 500 watt rms 2 ohm / 4 x 310 watt rms 4 ohm
Adjustable subwoofer filter with wired control INCLUDED
Dimensions 230x264x64mm
Filter High / Low Pass / Flat 15-20000hz
Bass Boost 1/ / 12 / 0db (35/70hz)
Frequency Response 20- 20000hz
S/N >100db
Input sensitivity 0.2v- 5v
Operating voltage 10.5-15.5v
3 Led Power, Clip, Protection.
POWER FUSE: 1x250A
Integrated active crossovers
Bass boost circuit
Ultra-efficient Class D topology
Wideband frequency response up to 20kHz
Full bridge technology
4-channel amplifier
1 Ohm stable
Compact design
50mm² power inputs
8mm² speaker outputs

Reference Edge Audio EDX800.4FD-E0

In stock 2 Items
