Faital 18FH510 - Subwoofer 18" Ferrite - 4ohm
Faital 18FH510 - Subwoofer 18" Ferrite - 4ohm

Faital 18FH510 - Subwoofer 18" Ferrite - 4ohm

Faital 18FH510 - Subwoofer 18" Ferrite - 4ohm

SHIPMENT IN 5-7 WORKING DAYS
€285.95 €301.00 -5%
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€27.48
Shipping Time
.
Want to check another country or courier?

You might also like



Faital 18FH510 - Subwoofer 18" Ferrite - 4ohm

NOMINAL SPECIFICATIONS

Nominal Diameter 460 mm (18 in)
Overall Diameter 460 mm (18.11 in)
Bolt Circle Diameter 440 mm (17.32 in)
Baffle Cutout Diameter 421 mm (16.57 in)
Depth 201.5 mm (7.93 in)
Flange and Gasket Thickness 13.7 mm (0.54 in)
Net Weight 8.8 Kg (19.3 lb)
Shipping Box
(Single Carton Box)		 503 x 500 x 258 mm
(19.8 x 19.7 x 10.2 in)
Shipping Weight 10.3 Kg (22.7 lb)



TECHNICAL PARAMETERS

Nominal Impedance 4 Ohm
Minimum Impedance 3.9 Ohm
AES Power Handling (1) 600 W
Maximum Power Handling (2) 1200 W
Sensitivity (1W/1m) 98 dB
Frequency Range 30÷2500 Hz
Voice Coil Diameter 77 mm (3 in)
Winding Material Cu
Former Material Glass Fiber
Winding Depth 22.4 mm (0.88 in)
Magnetic Gap Depth 10.5 mm (0.41 in)
Flux Density 1.2 T
Magnet Ferrite Ring
Basket Material Aluminum
Demodulation No
Cone Surround (3) Triple Roll
NET Air Volume filled by Loudspeaker 6.1 dm^3 (0.215 ft^3)
Spider Profile 1x variable height waves



QUICK MECHANICAL SPECS

Nominal Diameter 460 mm (18 in)
Overall Diameter 460 mm (18.11 in)
Bolt Circle Diameter 440 mm (17.32 in)
Baffle Cutout Diameter 421 mm (16.57 in)
Depth 201.5 mm (7.93 in)
Flange and Gasket Thickness 13.7 mm (0.54 in)
Net Weight 8.8 Kg (19.3 lb)
Shipping Box
(Single Carton Box)		 503 x 500 x 258 mm
(19.8 x 19.7 x 10.2 in)
Shipping Weight 10.3 Kg (22.7 lb)
18FH510
1 Item
