SB Acoustics SW26DBAC76-4 Subwoofer 10"

The SB Acoustics SW26DBAC76-4 Aluminum 10 inch 4 ohm shallow Subwoofer can give great low-end extension in a shallow enclosures due to its unique long trough design.

Estimated Shipping Costs
Shipping Costs
€19.20
Shipping Time
.
Want to check another country or courier?

You might also like



SB Acoustics SW26DBAC76-4 Subwoofer 10"

.

Product description

Unique patented long through shallow design

Powerful neodymium motor system

Vented cast aluminum cone structure

Non conducting fiber glass coil former for minimum damping

Shorting ring in motor system for reduced distortion

Long life silver lead wires

.

Product details

SB Acoustics SW26DBAC76-4 10" Aluminium Cone Subwoofer

The SB Acoustics SW26DBAC76-4 Aluminum 10 inch 4 ohm shallow Subwoofer can give great low-end extension in a shallow enclosures due to its unique long trough design. With a depth of only 70.5 mm its good for applications where clearance can become an issue. A sealed enclosure with a volume of 40Ltr is recommend for optimal performance. This driver is not recommended for a bass-reflex/ported enclosures.

.

Specifications

Article numberSW26DBAC76-4
Woofer TypeSubwoofer
Nominal Diameter10''
Power Handling (RMS)200 Watts
Impedance (Z)4 Ohms
Sensitivity (SPL at 1m / 2.83V)86 dB
Voice Coil Diameter75.5 mm
Magnet Weight281 g
DC Resistance (Re)3.2 Ohms
Resonant Frequency (Fs)22 Hz
Mechanical Q (Qms)4.5
Electromagnetic Q (Qes)0.51
Total Q (Qts)0.46
Diaphragm Mass Inc. Airload (Mms)134 g
Mechanical Compliance of Suspension (Cms)0.39 mm/N
Surface Area of Cone (Sd)312 cm2
BL Product (BL)10.8 Tm
Compliance Equivalent Volume (Vas)54 Ltr
Maximum Linear Excursion (Xmax)12 mm
Driver's Mechanical Losses (Rms)4.1 kg/s
Cone / Diaphragm MaterialAluminum
Voice Coil Wire MaterialCopper
Voice Coil FormerFiber glass
Basket / Frame MaterialAluminum
Magnet MaterialNeodynium
Overall Outside Diameter290 mm
Overall Depth84,6 mm
# Mounting Holes8
Mounting Hole Diameter249 mm
Sealed Volume40 ltr.
Vented VolumeNot recommended
