STETSOM BRAVO5K _1 Amplifier mono 1 ohm

Stetsom BRAVO5K – 1 Ohm The BRAVO line was developed for automotive sound lovers who are looking for maximum performance in BASS and SUB BASS.

Its 8Hz to 600Hz frequency response delivers powerful bass with quality and definition, for use with subwoofers and woofers.

TECHNICAL SPECIFICATIONS

Stetsom BRAVO 5K Subwoofer Amplifier MONO 1x5000W RMS into 1 ohm

Number of channels 1

RMS power 5000W

RMS power at 1 Ohm 14.4V 5200W

RMS power at 2 Ohm 14.4V 2900W

Supply voltage 9V ~ 17V DC

Frequency Response 5Hz ~ 600Hz (Flat ON)

Low pass crossover 30Hz ~ 250Hz

Crossover high pass 5Hz ~ 40Hz

Signal to noise ratio >90dB

Input sensitivity 200mV

Input impedance 4.8K Ohms

Output impedance 1 Ohm

Consumption with Signal Musical 228A

Consumption with Signal Bass 456A

Dimensions (H x W x D) mm 80 x 231.5 x 333 mm

Weight 4,31 Kg
