Mundorf MCAP Classic 400V 1 to 22µF 3% axial

Available with different values 1 to 22µF

To select the version go to the drop-down below the price

Mundorf describes the MCap as a fast, audiophile MKP capacitor, featuring a lively reproduction of music. This capacitor type is only surpassed in its performance by the MCap Supreme.

The MCap® is an audiophile metallized polypropylene capacitor. In selection of the materials used, special attention was given to the sound properties. The practically induction-free type of construction and the low loss factor of the MCap® results in a very “quick” capacitor. The MCap® forms the basis for vivid music reproduction rich in nuance. True to our motto of “Inner Excellence”, the best material selection and highest production quality guarantee low tolerances and the highest standards of safety in use, even in our entry-level model. The MCap® Classic’s three-dimensional, precise sound pattern, the richly detailed, harmonic music playback and dynamics are guaranteed with aluminised PP capacitor film.

Specifications: Dielectric: Polypropylen • Dielectric strengh: 250-630 VDC • Metall-foil: 6 μm Tin • Loss factor: tan∂ = 0.0002@1kHz@1μF • Permissible ambient temperature 85°C/185°F
