Cerwin-Vega VCU84 Amplifier 4 channel class D

Cerwin-Vega Mobile launches the latest mini digital version of the Vega final stages with a host of additional features added to the previous model. The latest Vega final steps receive high-level input with auto power on for increased compatibility and application purposes. The newly designed and advanced power and the heat protection circuit ensure that the final stages play continuously when operated under the most extreme conditions.

Characteristics:

     Ultra-compact high-density chassis with aluminum alloy
     Advanced power / heat protection circuit
     BTR ™ Port - Enables upgrading to Bluetooth
     Class D IR Chipset with DirectFET Power Mosfet output

Technical data

Model Cerwin-Vega VCU84
Product ID VCU84
Number of channels 4
Amplifier class D
Max power 600W
Power 4ohm RMS 4x90W
Power 2ohm RMS 4x165W
Power 4ohm bridge coupled RMS 2x275W
THD 0.25%
Recommended ground / power cable 25mm2
Low pass filter 40Hz-400Hz
Bass remote / remote control No
Bass boost Yes
Signal Noise 101.7dBa
Frequency range 10Hz-33KHz
Input sensitivity 200mV-10.0V
Operating voltage 11-16V
Dimensions 35.5x102.1x221mm
