Cerwin Vega XED 6004D 4 channel amplifier

The new XED amplifiers are small and compact and work with Class D technology. The advantage of KlassD technology is that they do not overheat and draw very little power due to their high efficiency. The amplifier is suitable for medium-power full-range speakers

.

Technical data

Number of channels 4

Amplifier class D

Maximum power 400W

Power in 2 ohms RMS 4x120W

Power in 4 ohms RMS 4x80W

Frequency range 10Hz-30KHz

High pass filter Yes 35Hz-250Hz

Low pass filter Yes 35Hz-250Hz

Bass remote / remote control Yes

Attenuation factor >70

Input sensitivity 250mV - 6.0V

Recommended power and ground cable 10mm2

THD <0.1%

Low level output No

Dimensions 180 x 120 x 46.5 mm
