GAS MAD A1-70.2 2-channel amplifier

GAS MAD A1-70.2 is a 2-channel analog car amplifier with a power of 2x 70/105 W or 1x 220 W RMS.

Always think about what you can achieve in your speakers with a powerful drive. To maintain high volume levels and low heating, the MAD A1-70.2 is equipped with its own A-Star cooler with an increased cooling surface. Thanks to this, less material is consumed, the same efficiency is achieved and a great appearance is maintained.

Want to get your amp installed as quickly as possible so you can get out there and show the world just how LOUD your sound system can be? Then the A1-70.2 is just for you. In addition, you will find the CLIP function for easy installation to help you detect when 1% distortion is reached, the latest high-level input technology with ATO, automatic switching on based on signal reception. The MAD A1-70.2 provides you with 12dB slope LPF and HPF filters with a wide range of features. Build the system of your dreams, the choice is yours - but make sure it's loud! Even the most modern protection circuits are used for maximum service life. This minimizes the risk of undervoltage, thermal overload and short circuits!

.

Technical Specifications

• RMS power: 2x 70/105 W at 4/2 Ohms
• Bridge RMS power: 1x 220 W at 4 Ohms
• Frequency range: 15-22000 Hz
• Harmonic Distortion THD: 0.5%
• Signal-to-Noise ratio: >98 dB
• Input sensitivity: 0.5-6 V
• Built-in high pass HPF 50-4000 Hz
• Built-in low-pass filter LPF 50-4000 Hz
• Built-in Bass Boost 0-12 dB at 45 Hz
• Working voltage: 10-16 V
• Damping Factor: >130
• Fuse: 1x 35 A
• Dimensions: 252x209x55 mm (WxDxH)
