Audio System HX 360.2 2 channel amplifier

• 2-channel high power amplifier in class AB operation with SMD technology
• Full MOS-FET power amp
• Last stable to 1 ohm per channel stereo and 2 ohms in bridged mode
• Variable low pass filter from 50 to 300 Hz with ON / OFF switch
• Variable high pass filter 25-175 Hz with ON / OFF switch
• Variable bandpass filter of 25 to 300 Hz with ON / OFF switch
• Variable phase shift filter of 0 to 360 °
• Selectable mono or stereo input switch
• 12dB / 24dB slope adjustable
• Extremely wide-ranging input sensitivity of 0.2 to 8 V
• Effizeintes security system (MWPC) against overheating, over voltage, short circuit and before
• DC voltage at the loudspeaker output
• Operating voltage of 10 ~ 16 V
• Solid aluminum heat sink with supporting fan cooling
• Wired remote control RTC HX (Optional)
• DIRECT INPUT switch
• HX CARD slots for individual turnout vote
• Automatic switching on Board - "TURN ON" on High Level Input (RCA input)

• Burr-Brown preamplifier
•  1 Ohm Stereo / Mono 2 ohms stable
•  real "direct  to" (RDI), continuously variable temperature-dependent fan cooling
•  efficient  analog amplifier
•  very high efficiency
•  variable phase shift from 0-360 °,
• elegant design
• Subsonic filter
• efficient security system (MWPC),
• extremely wide-ranging input sensitivity of 0.2 to 8 V
• 2x 360 Watts RMS @ 4 ohms stereo
• 2x 650 watts RMS @ 2 ohms stereo
• 2x 1250 watts RMS @ 1 Ohm stereo
• 1x 1250 watts RMS @ 4 ohms mono
• 1x 2500 watts RMS @ 2 ohms mono

Dimensions: 706 (L) x 240 (W) x 56 (H) mm
