Deaf Bonce Machete MFA-2.420 amplifier 2 channel

Product description

The Apocalypse MFA-2.420 is a powerful 2-channel Class D amplifier that impresses with its compact design and outstanding performance. This final stage is perfect for those who want to achieve an extremely high sound level with strong mid-bass. With a full 2x630W rms at 2 ohms (at 14.4V), you can drive up to 4 pieces of 4 ohm mid-bass with full power.

The MFA-2.420 uses Class D amplifier class, which makes it less sensitive to overheating and more efficient in terms of power consumption. You can be sure that this power stage delivers reliable and impressive performance without compromising stability and efficiency. With a power of 630W x 2 at 2 ohms and 420W x 2 at 4 ohms, this power amplifier offers outstanding performance across the entire frequency range from 20 Hz to 20,000 Hz. Its high-pass filter is adjustable between 15 Hz and 12,000 Hz, while the low-pass filter can be fine-tuned between 50 Hz and 12,000 Hz to give you maximum control over the sound.

The MFA-2.420 also has a subsonic filter to prevent low frequencies outside the audible range from overloading the speakers. In addition, the power stage comes with a handy bass remote/remote control that allows you to adjust the bass level directly from the driver's seat. This versatile power amplifier has an operating voltage of 9V to 15V and an input sensitivity of 0.4V to 8V, giving you flexibility and customization options for different audio setups and settings.

With the Apocalypse MFA-2.420 you get a powerful, reliable and flexible power amplifier that will take your audio experience to new levels. Whether you're looking to play loud with powerful mid-bass or just want an impressive sound quality, this power amplifier will deliver impressive performance that will give you an extraordinary musical experience.

.

Specifications

Model MFA-2.420

Class D

Number of channels 2

Frequency range 20-20000 Hz

Power RMS @ 2 ohms (14.4V) 630W x 2

Power RMS @ 4 ohms (14.4V) 420Wx2

Power RMS @ 4 ohms (Bridge) 1260W x 1

Minimum load resistance per channel 2 ohm

Minimum load resistance in bridged mode 4 ohm

Input sensitivity 0.4 - 8 V

Low pass filter 50-12000 Hz

High pass filter 50-12000 Hz

Simultaneous activation of LPF and HPF Yes

crossover 12 dB/Oct

input terminal 4 Ga

output terminal 10 Ga

Working voltage 9 - 15 V

Signal/Noise ≥ 90 dB

Dimensions (LxWxH) 151.9 x 237.0 x 54.7mm

Shipping Weight 2.36 kg

Equipment Amplifier, mounting kit, manual, warranty card
