NOMINAL SPECIFICATIONS
Nominal Diameter | 380 mm (15 in) |
Overall Diameter | 393 mm (15.47 in) |
Bolt Circle Diameter | 374 mm (14.72 in) |
Baffle Cutout Diameter | 354 mm (13.94 in) |
Depth | 217 mm (8.54 in) |
Flange and Gasket Thickness | 14 mm (0.55 in) |
Net Weight | 11.8 Kg (25.9 lb) |
Shipping Box (Single Carton Box) | 422 x 417 x 264 mm (16.6 x 16.4 x 10.4 in) |
Shipping Weight | 13.5 Kg (29.8 lb) |
TECHNICAL PARAMETERS
Nominal Impedance | 4 Ohm |
Minimum Impedance | 4.4 Ohm |
AES Power Handling (1) | 1400 W |
Maximum Power Handling (2) | 2800 W |
Sensitivity (1W/1m) | 96 dB |
Frequency Range | 40÷2500 Hz |
Voice Coil Diameter | 100 mm (4 in) |
Winding Material | Cu |
Former Material | Glass Fiber |
Winding Depth | 31 mm (1.22 in) |
Magnetic Gap Depth | 15.5 mm (0.61 in) |
Flux Density | 0.98 T |
Magnet | Neodymium Slug Crown |
Basket Material | Aluminum |
Demodulation | Triple Al Dem. Ring |
Cone Surround (3) | Triple Roll |
NET Air Volume filled by Loudspeaker | 6 dm^3 (0.212 ft^3) |
Spider Profile | 2x non-adjacent symmetrical constant height waves |
QUICK ACOUSTIC SPECS
Nominal Impedance | 4 Ohm |
Minimum Impedance | 4.4 Ohm |
AES Power Handling (1) | 1400 W |
Sensitivity (1W/1m) | 96 dB |
Frequency Range | 40÷2500 Hz |
Flux Density | 0.98 T |
Magnet | Neodymium Slug Crown |
Demodulation | Triple Al Dem. Ring |
Cone Surround (2) | Triple Roll |
Fs | 38 Hz |
Re | 3 Ohm |
Qes | 0.31 |
Qms | 10.3 |
Qts | 0.30 |
Vas | 84.3 dm^3 (2.98 ft^3) |
Sd | 841 cm^2 (130.36 in^2) |
Xmax (3) | 12.92 mm |
Xdamage (4) | 28 mm |
Mms | 205.4 g |
Bl | 21.7 N/A |
Le | 1.25 mH |
Mmd | 177.8 g |
Cms | 0.09 mm/N |
Rms | 4.8 Kg/s |
Eta Zero | 1.44 % |
EBP | 123 Hz |
QUICK MECHANICAL SPECS
Nominal Diameter | 380 mm (15 in) |
Overall Diameter | 393 mm (15.47 in) |
Bolt Circle Diameter | 374 mm (14.72 in) |
Baffle Cutout Diameter | 354 mm (13.94 in) |
Depth | 217 mm (8.54 in) |
Flange and Gasket Thickness | 14 mm (0.55 in) |
Net Weight | 11.8 Kg (25.9 lb) |
Shipping Box (Single Carton Box) | 422 x 417 x 264 mm (16.6 x 16.4 x 10.4 in) |
Shipping Weight | 13.5 Kg (29.8 lb) |
