Massive Audio BP1000.1 – MONO AMPLIFIER

Massive Audio BP1000.1 – 1000W FULL RANGE MONO AMPLIFIER WITH BUILT-IN OEM LINE CONVERTER

The BLADE BP Series Amplifiers are designed with our “Live, Loud and Play Hard” motto. All amplifiers have built-in OEM line converters with RCA inputs that can take a high level speaker signal at up to 9 Volts directly in. By sensing the DC off set of a factory radio it can activate the ATO (Auto Turn On) feature and convert the 12V turn on into a 12V switched out. Blade “BP” are Class AB designed with a minimum per channel impedance operation of 2 Ohm with the exception of the BP2000.1, BP1200.1 which are Class “D” and can play down to 1 Ohm minimum. The monster BP4000 & BP6000 are full range Digital and 2 OHM stable. All Blade “BP” amps use Mil Spec PCBs, SMD parts, 5 way protection, full MOSFET high grade switching devices and all comply with the “World Wide Standards”, “ROHS”, “E-Mark” and are CTA2006 Compliant. This ensures that no competition can stand up to the BLADE BP when it comes to features, performance and value.

FEATURES:

• Built-In OEM Line Converter
• Low Pass Frequency / OFF Crossovers
• Up to 9 Volt Input via RCA or High Level Speaker Leads
• Bass Boost 0dB ~ 12dB @ 45Hz
• Built-in Noise Reduction Circuitry
• Full MOSFET with High Grade Switching Devices
• Built-In, DC Offset, Auto Sensing Turn On Function (Hi-Level Inputs)
• 12V Remote Output for External Devices (Hi-Level Inputs)
• Variable Low Pass Crossover Frequencies from 50Hz ~ 750Hz
• Ground Loop Isolator
• Next Generation Advanced 5 Way Protection Circuitry
• High Output Power Supply & Dual Output Voltage
• Mil Spec PCB with SMD parts
• World Wide Standards Compliant (RoHS, E-Mark, CTA-2006, CE)

SPECIFICATIONS:

Peak Output Power @ 14.4V 1000W x 1
1 Ohm RMS n / a
2 Ohm RMS 455W x 1
4 Ohm RMS 250W x 1
4 Ohm Bridged n / a
Input Level 0.2 ~ 9.0v
Freq. Response 15Hz ~ 35KHz
THD at 4 Ohm Load 30% Rated Power <0.1%
S / N Ratio> 90dB
Bass Boost 0 ~ 6dB / 12dB (45Hz)
Minimum Load 2 Ohm Mono
Gain Remote UR1 (Optional)
Dimension 2 "H x 7.1" W x 12.9 "L
