SHIPMENT IN 7-10 WORKING DAYS
€179.00
Tax included
rating No review at the moment

SB ACOUSTICS SATORI MW16P-4 - 6.5" Midwoofer - 4ohm

The MW16P-4 is a 4 ohm mid-woofer from the SB Acoustics Satori series. Satori is a Buddhist term for enlightenment. The word literally means "understanding".  Satori translates as a flash of awareness.

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



SB ACOUSTICS SATORI MW16P-4 - 6.5" Midwoofer - 4ohm

.

Product description

Egyptian Reed Cone

Vented aerodynamic cast aluminum chassis for optimum strength and low compression

Proprietary cone material with EGYPTIAN PAPYRUS fibers made in-house

Soft low damping rubber surround for optimum transient response

Advanced BIMAX spider for improved linearity

Powerful optimized low distortion neodymium motor system

Non-conducting fiber glass voice coil former for minimum damping

Extended copper sleeve on pole piece for low inductance and reduced distortion

CCAW voice coil for reduced moving mass

Long life silver lead wires attached 180° apart for improved stability

Vented pole piece for reduced compression

High piston to chassis diameter ratio

Gasket and bolt hole protrusions for reduced coupling to speaker cabinet

.

Product details

SB Acoustics Satori MW16P-4 6" Egyptian Papyrus Cone Woofer

The MW16P-4 is a 4 ohm mid-woofer from the SB Acoustics Satori series. Satori is a Buddhist term for enlightenment. The word literally means "understanding".  Satori translates as a flash of awareness.  Satori drivers are designed for subtlety and realism.

The driver has very nice looks and building quality. The small but yet powerful neodymium magnet together with the shape of the chassis contributes to an optimal airflow behavior.

.

Specifications

Article numberMW16P-4
Woofer SeriesSatori Series
Woofer TypeMidwoofer
Nominal Diameter6"
Power Handling (RMS)60 Watts
Impedance (Z)4 ohms
Sensitivity (SPL at 1m / 2.83V)90.5 dB
Voice Coil Diameter1.41"
DC Resistance (Re)3.4 ohms
Voice Coil Inductance (Le)0.2 mH
Resonant Frequency (Fs)28 Hz
Electromagnetic Q (Qes)0.28
Total Q (Qts)0.27
Diaphragm Mass Inc. Airload (Mms)12.8 g
Mechanical Compliance of Suspension (Cms)2.5 mm/N
Surface Area of Cone (Sd)119 cm2
BL Product (BL)5.2 Tm
Compliance Equivalent Volume (Vas)1.77 ft.³
Maximum Linear Excursion (Xmax)6 mm

MW16P-4
