FAITAL 6PR160 - Midrange 6" - Neodimio - 8ohm
FAITAL 6PR160 - Midrange 6" - Neodimio - 8ohm

FAITAL 6PR160 - Midrange 6" - Neodimio - 8ohm

SHIPMENT IN 7-10 WORKING DAYS
€140.60 €148.00 -5%
Tax included
rating No review at the moment

FAITAL 6PR160 - Midrange 6" - Neodimio - 8ohm

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



FAITAL 6PR160 - Midrange 6" - Neodimio - 8ohm

Nominal Specifications

Nominal Diameter 160 mm (6 in)
Overall Diameter 186.5/162 mm (7.34/6.37 in)
Bolt Circle Diameter 172 mm (6.77 in)
Baffle Cutout Diameter 147 mm (5.79 in)
Depth 73 mm (2.87 in)
Flange and Gasket Thickness 9 mm (0.35 in)
Net Weight 1 Kg (2.2 lb)
Shipping Box
(Single Carton Box)		 190 x 185 x 103 mm
(7.5 x 7.3 x 4.1 in)
Shipping Weight 1.1 Kg (2.4 lb)



Technical Parameters

Nominal Impedance 8 Ohm
Minimum Impedance 7 Ohm
AES Power Handling (1) 120 W
Maximum Power Handling (2) 240 W
Sensitivity (1W/1m) 95 dB
Frequency Range 80÷8000 Hz
Voice Coil Diameter 37 mm (1.46 in)
Winding Material Al
Former Material Glass Fiber
Winding Depth 12 mm (0.47 in)
Magnetic Gap Depth 6 mm (0.24 in)
Flux Density 1.6 T
Magnet Neodymium Ring
Basket Material Aluminum
Demodulation Aluminum Ring
Cone Surround (3) Triple Roll
NET Air Volume filled by Loudspeaker 0.37 dm^3 (0.013 ft^3)
Spider Profile 1x constant height waves

6PR160_response_8.gif 6PR160_impedance_8.gif

Quick acoustic specs

Nominal Impedance 8 Ohm
Minimum Impedance 7 Ohm
AES Power Handling (1) 120 W
Sensitivity (1W/1m) 95 dB
Frequency Range 80÷8000 Hz
Flux Density 1.6 T
Magnet Neodymium Ring
Demodulation Aluminum Ring
Cone Surround (2) Triple Roll
Fs 90 Hz
Re 5.9 Ohm
Qes 0.35
Qms 6.6
Qts 0.33
Vas 5.9 dm^3 (0.21 ft^3)
Sd 130 cm^2 (20.10 in^2)
Xmax (3) 5.00 mm
Xdamage (4) 11.6 mm
Mms 12.5 g
Bl 11 N/A
Le 0.28 mH
Mmd 10.8 g
Cms 0.25 mm/N
Rms 1.1 Kg/s
Eta Zero 1.21 %
EBP 261 Hz


Quick mechanical specs

Nominal Diameter 160 mm (6 in)
Overall Diameter 186.5/162 mm (7.34/6.37 in)
Bolt Circle Diameter 172 mm (6.77 in)
Baffle Cutout Diameter 147 mm (5.79 in)
Depth 73 mm (2.87 in)
Flange and Gasket Thickness 9 mm (0.35 in)
Net Weight 1 Kg (2.2 lb)
Shipping Box
(Single Carton Box)		 190 x 185 x 103 mm
(7.5 x 7.3 x 4.1 in)
Shipping Weight 1.1 Kg (2.4 lb)
6PR160
