SB ACOUSTICS SB13PFC25-4-Coax 5"

SB ACOUSTICS SB13PFC25-4-Coax 5"

SHIPMENT IN 7-10 WORKING DAYS
€53.20
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



SB ACOUSTICS SB13PFC25-4-Coax 5"


The SB Acoustics SB13PFC25-4-COAX is composed by a vented reinforced plastic chassis and a proprietary cone material with natural made in-house fibers. The soft low damping rubber surround allows an improved transient response. Optimized motor system, non-resonant long life lead wires and compact large surround dome tweeter.

Highlights

Vented reinforced plastic chassis
Proprietary cone material with natural fibers made in-house
Soft low damping rubber surround for improved transient response
Optimized motor system
Non-resonant long life lead wires
Compact large surround dome tweeter

Brand SB Acoustics
Series OEM
Magnet Material Ferrite
Diaphragm Material Fabric
Diaphragm Diameter [mm] 25
Free Air Resonance [Hz] 43
Impedance [Ohm] 4
Sensitivity [dB] 90
Power Handling [Watt] 40
Cone Material Fibers
Cone Diameter [inch] 5
Qts 0,27
Impedenza nominale 4 Ω 4 Ω
Re 3.2 Ω 3.0 Ω
Sensibilità  1W/1m 90 dB 89 dB
fs 43 Hz 1.300 Hz
Qes 0.3 -
Qms 2.26 -
Qts 0.27 -
Vas 17 l -
Sd 89.9 cm^2  -
Xmax 4.6 mm -
Xdamage - -
Mms 9.1 g -
Bl 5.1 N/A -
Le 0.30 mH -
Mmd - -
Cms 1.51 mm/N -
Rms - -
Eta Zero - -
EBP - -

SB13PFC25-4
