Deaf Bonce Machete MFA-2.220 amplifier 2 channel

The MFA-2.220 is a powerful 2-channel Class D power amplifier in a compact design. Suitable for those who want to play extremely loud with strong mid-bass. With a full 2x350W rms (14.4V) in 2ohms, you can drive up to 4 4ohm midbass.

Slutseget works in Class D, which makes them insensitive to overheating

.

Specifications

Model MFA-2.220

Class D

Number of channels 2

Frequency range 20-20000 Hz

Power RMS @ 2 ohms (14.4V) 350Wx2

Power RMS @ 4 ohms (14.4V) 220W x 2

Power RMS @ 4 ohms (Bridge) 700Wx1

Minimum load resistance per channel 2 ohm

Minimum load resistance in bridged mode 4 ohm

Input sensitivity 0.4 - 8 V

Low pass filter 50-12000 Hz

High pass filter 50-12000 Hz

Simultaneous activation of LPF and HPF Yes

crossover 12 dB/Oct

input terminal 4 Ga

output terminal 10 Ga

Working voltage 9 - 15 V

Signal/Noise ≥ 90 dB

Dimensions (LxWxH) 151.9 x 218.0 x 54.7mm

Shipping Weight 2.00 kg

Equipment Amplifier, mounting kit, manual, warranty card
