Faital HF108R - Compression Driver 1" Neodimio - 8ohm
Faital HF108R - Compression Driver 1" Neodimio - 8ohm
  • -5%
Faital HF108R - Compression Driver 1" Neodimio - 8ohm
Faital HF108R - Compression Driver 1" Neodimio - 8ohm

Faital HF108R - Compression Driver 1" Neodimio - 8ohm

SHIPMENT IN 7-10 WORKING DAYS
€194.74 €204.99 -5%
Tax included
rating No review at the moment

Faital HF108R - Compression Driver 1"  Neodimio - 8ohm

Estimated Shipping Costs
Shipping Costs
€15.00
Shipping Time
.
Want to check another country or courier?

You might also like



Faital HF108R - Compression Driver 1"  Neodimio - 8ohm

TECHNICAL PARAMETERS

Nominal Impedance8 Ohm
Minimum Impedance6.5 Ohm
AES Power Handling (1)60 W
Maximum Power Handling (2)120 W
Minimum Crossover Frequency (3)1.3 kHz
Sensitivity (1W/1m) (4)109 dB
Frequency Range1÷20 kHz
Voice Coil Diameter44 mm (1.73 in)
Winding MaterialAl
Former MaterialKapton
Diaphragm MaterialKetone Polymer
Diaphragm ShapeDome
Winding Depth2.3 mm (0.09 in)
Magnetic Gap Depth2.85 mm (0.11 in)
Flux Density2.1 T
MagnetNeodymium Ring
Re5.8 Ohm
Phase Plug DesignAnnular
Exit Angle (5)31° Conical
NET Air Volume filled by HF Driver0.195 dm^3 (0.007 ft^3)

NOMINAL SPECIFICATIONS

Throat Diameter25.4 mm (1 in)
Overall Diameter87 mm (3.43 in)
180° Mounting Holes Diameter (2xM5)76 mm (2.99 in)
Depth41 mm (1.61 in)
Net Weight800 g (1.8 lb)
Shipping Box
(Single carton box)		147 x 130 x 82 mm
(5.8 x 5.1 x 3.2 in)
Shipping Weight1.2 kg (2.6 lb)


QUICK ACOUSTIC SPECS

Nominal Impedance8 Ohm
Minimum Impedance6.5 Ohm
AES Power Handling (1)60 W
Maximum Power Handling (2)120 W
Minimum Crossover Frequency (3)1.3 kHz
Sensitivity (1W/1m) (4)109 dB
Frequency Range1÷20 kHz
Voice Coil Diameter44 mm (1.73 in)
Diaphragm MaterialKetone Polymer
Diaphragm ShapeDome
Flux Density2.1 T
Re5.8 Ohm
Phase Plug DesignAnnular


QUICK MECHANICAL SPECS

Throat Diameter25.4 mm (1 in)
Overall Diameter87 mm (3.43 in)
180° Mounting Holes Diameter (2xM5)76 mm (2.99 in)
Depth41 mm (1.61 in)
Net Weight800 g (1.8 lb)
Shipping Box
(Single carton box)		147 x 130 x 82 mm
(5.8 x 5.1 x 3.2 in)
Shipping Weight1.2 kg (2.6 lb)
