    Dynavin D8-83S Pro Navigation VW Golf 5 plus

    • Premium 9"/16:9 LCD capacitive touchscreen display (1240 x720 resolution).
    • Support Wireless Apple CarPlay, Apple CarPlay and Android Auto.
    • Support SmartPhone Mirroring.
    • Preinstalled with Google Play Store. Connecting to the internet through built-in Wifi module.
    • CANBUS solution integration for steering wheel controls.
    • BT for audio streaming and hands-free phone calls via any smartphone (Android, Apple, etc.). External microphone included.
    • FM RDS TMC tuner with DSP noise masking and 15 preset stations, built-in DAB. Supports switching back and forth automatically between DAB and FM (Seamless Blending).
    • Integrated Sound DSP processor with 9-bands EQ and time correction.

    Estimated Shipping Costs
    Shipping Costs
    €18.00
    Shipping Time
    .
    Want to check another country or courier?



    Dynavin D8-83S Pro Navigation VW Golf 5 plus

    Suitable for

    VW Golf 5 plus, Tiguan 2007-2017

    Highlights

    • Premium 9"/16:9 LCD capacitive touchscreen display (1240 x720 resolution).
    • Support Wireless Apple CarPlay, Apple CarPlay and Android Auto.
    • Support SmartPhone Mirroring.
    • Preinstalled with Google Play Store. Connecting to the internet through built-in Wifi module.
    • CANBUS solution integration for steering wheel controls.
    • BT for audio streaming and hands-free phone calls via any smartphone (Android, Apple, etc.). External microphone included.
    • FM RDS TMC tuner with DSP noise masking and 15 preset stations, built-in DAB. Supports switching back and forth automatically between DAB and FM (Seamless Blending).
    • Integrated Sound DSP processor with 9-bands EQ and time correction.
    • AV input/output for aftermarket subs/amps, etc.
    • Multimedia player by USB connectivity.
    • Built-in navigation software with 3D view and premium POI.

    Technical Data

    General

    • Android 8.1 OS with 2 GB RAM and 32 GB or 160 GB ROM
    • Power Output: 4 x 45 W High Power Amplifier
    • 3 PreOuts (3 V, Front / Rear / Subwoofer)
    • CANBUS Integration
    • Menu Language: English / German / French / Spanish / Portuguese / Dutch / Greek / Italian / Polish / Danish
    • Camera Connection & Built-in Controls for Dynavision Multi-View Cameras / compatible with factory camera
    • Camera Guideline Adjustment
    • Rear-view Camera Display Automatic / Fast Boot-up
    • 9 Band EQ
    • Auto Dimmer
    • Firmware Updatable
    • Engine Start-Stop unaffected

    Screen

    • Display: 9-inch (LVDS)
    • Resolution 1240 x 720 pixels (RGB)
    • Capacitive touch screen
    • Anti-reflection display
    • Working system: TFT Active Matrix
    • Active area: 196.608 (H) x 114.15 (V) mm

    Z-Link

    • Works with wireless Apple CarPlay and Apple Carplay
    • Works with Android Auto
    • Works with Smart Phone Mirroring

    DAB+

    • DAB/DAB+ build-in
    • DAB + to DAB + Service Compatible
    • Seamless Blending (automatic switching between DAB + and FM )
    • SLS (Slideshow Service)
    • DLS (Dynamic Label Service)
    • Radio VIS (station cover on your radio display)
    • Station memory: 15 program memory locations

    Build-in BT

    • Integrated BT module
    • Specification standard: 3.0sands2.1+EDR
    • -95dBm sensitivity, excellent anti-interference performance
    • Supports low-power scanning function
    • PBAP phonebook synchronization with 1000 entries
    • Hands-free function with HFP
    • Music streaming: A2DP (Advanced Audio Distribution Profile) compatible
    • Individual profile connection: hands-free function and music streaming
    • Phonebook: Automatic phonebook transfer
    • Supports dashboard display for caller alerts
    • Supports saving pairing information for multiple phones
    • Device name display
    • Call list: dialed number / received calls / missed calls
    • Speech volume setting: adjustable for incoming and outgoing calls
    • Microphone gain adjustable
    • Display of the GSM signal strength
    • Display of the battery charge level

    GPS

    • GPS antenna included
    • GPS reception frequency 1,575.42 ± 1 MHz
    • GPS reception sensitivity -165 dB max
    • Positioning accuracy: 10 m, 2D RMS
    • Data update rate: 1 HZ
    • Recapture time: 0.1 s on average

    USB

    • USB specification: USB 2.0, fast charging support
    • Audio playback (supported formats: APE/FLAC/M4A/MP3/WMA/WAV)
    • Video playback (supported formats: MPEG-4/AVI/FLV/MPEG/MPG/DAT/VOB/MKV)
    • Image browsing (supported formats: JPG/BMP/PNG/JPEG)
    • Playback mode: random play / single song loop / all loop / folder loop
    • Picture can be set as starting screen
    • Sync song album images
    • Draggable progress bar
    • Video playback speed x2/ x4
    • Memory playback progress
    • Supports dashboard display of songs/composers
    • Supports steering wheel to control up/down song/volume level
    • File / Folder name search
    • Supports up to 256 GB USB storage device

    A2DP

    • BT audio streaming from cell phone
    • Display song title/lyrics/composer/vocalist
    • Steering wheel can control up/down song/volume level
    • Song title/lyrics can be displayed on the dashboard

    Sound tuning

    • Maximum output power: 4 x 45 W
    • Adjustable subwoofer level
    • Subwoofer, Bass, Middle, Treble phase selectable
    • Equalizer Presets: Pop, Rock, Classical
    • 9-band parametric equalizer
    • Fader and balance
    • Digital time correction

    Radio

    • FM frequency range: 87.5 – 108.0 MHz
    • AM frequency range: 530 – 1710 KHZ
    • FM Utility Sensitivity: 5-6 db
    • FM Stop Sensitivity: 22 db
    • AM stop sensitivity: 21 db
    • With left and right stereo channels
    • Signal to noise ratio: 56 db
    • Manual station storage for 15 stations
    • RDS functions: AF, TA, broadcast text
    • Automatic station tracking function
    • High Cut high frequency attenuation function
    • Support for changing FM/AM memory station pictures
    • Optional radio antenna power on/off

    Navigation

    • Maps: Full European map with 46 countries
    • Menu languages: 28 languages
    • Advanced address search
    • Postcode search
    • Free search
    • Search with word pieces
    • Extended POI functions
    • Smart routes: use of historical traffic data
    • Fast route calculation
    • Extended route planning
    • Map display: 2D top view, 2D north orientation, 3D
    • 3D city maps: 3D building views
    • Display of elevation profiles
    • 3D motorway junctions: 3D display of motorway junctions
    • Tunnel mode
    • Highway mode
    • Navi Mix mode
    • Free map update after the first registration on naviextras.com
