Kenwood DMX5020BTS radio Bluetooth USB Carplay Android Auto

.

Experience powerful audio performance with the Kenwood DMX5020BTS. This 2-DIN car radio scores with a wealth of innovative features for flawless sound and user-friendliness. Its main features include a 6.8" WVGA capacitive touchscreen, built-in Bluetooth, 2 pre-amp outputs and subwoofer, 13-band EQ and much more. With the DMX5020BTS model, Kenwood has launched a device that offers every driver that special something thanks to Apple CarPlay® and Android Auto™ compatibility, AV input, video output and rear view camera input and a user-friendly interface.

Specifications

• 6.8" WVGA capacitive touchscreen - White button illumination
• Apple CarPlay® & Android Auto™ ready
• Android USB mirroring capable
• Built-in Bluetooth
• Bluetooth ready for wireless music playback
• 2 pre-amp outputs + subwoofer (2.0V)
• 13 Band EQ - DSP - DTA Built-in
• AV input, video output & RCAM input
• Rear view camera input with built-in parking aid lines
• Short Chassis for easy installation

General Features

• DIN Size 2 DIN
• Smooth GUI Yes
• Selectable GUI Wallpaper Yes
• Key Illumination White Color
• Smooth Volume Reset Attenuator Yes
• Touch Sensor Tone Yes
• Optional IR Remote Control Yes, (KNA-RCDV331)
• Digital Clock (24 Hours) Yes
• ISO Connector Yes
• Built-in Bluetooth Yes
• iPod Ready Yes
• Works with Apple CarPlay Yes
• Works with Android Auto Yes
• Android USB Mirroring Yes
• Firmware Upgradable Yes

Monitor Features

• Screen Type 6.8" Wide VGA
• Display Mode 4 Modes (Full/Zoom/Normal/Auto)
• Screen Adjustments Brightness/Tint/Color/Contrast
• Dimmer Function Manual/Sync
• Dimming Level Yes
• Image Source Mode Mirrorring / CarPlay / Android Auto.
• Display Type Anti-Glare
• Screen Film Anti-Fingerprint
• Display Panel Capacitive
• Mechanism Type Fixed
• NTSC/PAL Switch Yes (Auto)
• Display Off Mode Yes

Multimedia GUI Functions

• OSDC Type Graphic
• Menu Text 14 Languages:
• English(UK)(Default)
• English(US)
• Spanish
• French
• German
• Italian
• Dutch
• Russian
• Portuguese
• Hebrew
• Greek
• Polish
• Czech
• Hungarian
• Software Updates (SoC)
• Demonstration Mode Yes
• Top Menu Customize Yes
• Splash Screen Type Standard
• Background Customize 6 x Presets + 2 x User Setting
• R-CAM Interrupt Yes
• R-CAM Parking Guidelines Yes

Tuner Functions

• Station Selection Manual / Preset (List)
• FM Reception Yes
• FM Stereo / Mono Selection Yes
• AM (MW/LW) Reception Yes
• Tuning Mode Auto1/Auto2/Manual
• Up/Down search/Scan Yes
• Tuner presets (FM/AM) 20 presets (15FM / 15AM)
• Automatic memory entry (AME) Yes
• Radio Data System Yes
• Radio Text Plus Yes
• Traffic information Yes
• Local search Yes
• AF Regional selectable: AF/AF Reg/OFF
• Enhanced Other Networks function (EON) Yes
• Program type function (PTY) Yes

General Bluetooth Features

• Max. number of registered phones for HFP & A2DP 7 phones
• Hands Free Profile (HPF) V1.6
• High Sound Quality Hands Free Profile HFP V1.6
• Audio Streaming (A2DP) Yes, (SBC/AAC)
• Serial Port Profile (SPP) Yes
• Simple Secure Pairing (SSP) Yes
• Phone Book Access Profile (PBAP) Yes
• Number of PBAP entries Up to 1000 phone book entries
• PBAP Call Log Up to 20 entries for dialed, received and missed calls
• Generic Access Profile (GAP) Yes
• Service Discovery Profile (SDP) Yes
• Audio/Video Remote Control Profile (AVRCP) Yes, V1.5
• Call Trace / Call Waiting Yes
• Private Mode Yes
• Alphabetical Search (Phone Book) Yes
• Voice Control Yes
• Noise Cancellation Yes
• Echo Cancellation Yes
• Signal Strength Display Yes
• Remaining battery indicator Yes
• Bluetooth pairing indicator Yes
• High quality noise cancelling microphone included
• Bluetooth firmware upgradable Yes, included in system updates

Playable audio file

• AAC (*.aac) files are playable USB
• MP3 files are playable USB
• WMA (.wma) files are playable USB
• WAV (.wav) files are playable USB
• FLAC files are playable USB

CE_Playable video file

• MPEG1/2 files are playable USB
• MPEG4 files are playable USB
• WMV files are playable USB
• H.264 files are playable USB
• Mkv files are playable USB
• JPEG files are playable USB

USB features

• USB port Yes, rear / 1m cable / fixed
• USB Type 2.0 High speed
• Works with Android Auto Yes
• Works with Apple CarPlay Yes
• USB Mirroring for Android install "Mirroring OA for KENWOOD" from the Playstore
• Repeat playback folder/file/all
• Random playback folder
• Category search Yes
• Link search Yes
• Resume playback Yes
• Time code display Yes
• 1.5A smartphone quick charge Yes

Audio functions

• Max. output power (MOSFET Power IC) 4 x 45 W
• Preamp output 2 RCA: FRONT/REAR + SUB(mono)
• Preamp output level 2 V
• Volume offset Yes
• Balance/fader control Yes
• Att.(-20dB) with soft volume return Yes
• Equalizer Yes, 13 band graphic EQ
• Digital sound processor (DSP) Yes
• Digital time adjustment (DTA) Yes
• Beep on/off Yes

Multimedia DSP functions

• Loudness Yes
• Bass boost Yes
• Car Type Control
• Off
• Compact
• Sedan
• Wagon
• Minivan
• SUV
• Passenger Car
• Speaker Size & Position Control Yes
• X'over Network 2-Way X'over / HPF / LPF
• Listening Position Control / Time Alignment Yes
• Equalizer Type Graphic
• Equalizer 13-Band
• Equalizer Presets / User Setting 7 Presets / 4 User Settings
• Balance & Fader Control Yes
• Source Volume Offset Source Independent
• Sound Effects
• Off
• Compact
• Sedan
• Wagon
• Minivan
• SUV
• Passenger Car
• Audio Setup Memory Yes

Video Features

• Audio-Video Output Yes, Video Only (RCA)
• Audio/Video Input Yes, Video and Audio Mini Jack
• Rear Camera Video Input 1 Dedicated Video Input (RCA)
• Rear Camera Detection Mode Reversing sensor cable
• Parking guide line Yes

Connectivity

• Wired OEM remote control possible Yes, optional interface required
• Programmable OEM steering wheel remote function Yes
• Cable for parking sensor (handbrake) Yes
• Cable for power control (P.CON) Yes
• Cable for dimmer control Yes
• Pre-amp output 2 x RCA (front/rear) + Sub (mono)
• AV input (non-switchable) (mini jack) Audio & Video
• Video output RCA x1
• Reversing sensor cable Yes
• Rear camera input Dedicated RCA video input
• FM antenna input JASO connector
• External microphone input 3.5mm mini jack

Tuner specifications

• FM range: 87.5Mhz - 108MHz (50Khz step) Yes
• FM usable sensitivity 1.8μV/75ohm (S/N 30dBf)
• FM frequency response 30Hz ~ 14kHz (± 3dB)
• FM Signal to Noise Ratio (Mono) 50dB
• FM Stereo Separation (1kHz) 35dB
• MW Range: 531kHz - 1611kHz (9kHz Step) Yes
• Usable MW Sensitivity 99μV

Bluetooth specifications

• Technology Bluetooth V4.1
• Frequency 2.402 - 2.48 GHz
• Output power +8dBm(max), power class 1
• Maximum range line of sight approx. 10 meters
• Handsfree profile (HFP) Yes, V 1.6
• Serial port profile (SPP) Yes
• Extended audio distribution profile (A2DP) Yes
• Audio codec SBC/AAC
• Phone book access profile (PBAP) Yes

USB specifications

• USB version compatibility USB 2.0 High Speed
• File system FAT 16/32, exFAT
• Maximum supply current 1500mA
• D/A converter 24bit
• Video decoder MPEG1/2/4, WMV, H.264, mkv
• Audio decoder MP3, WMA, AAC, WAV, FLAC

Audio specifications

• Maximum power 45W x 4
• Output power (DIN45324,+B=14.4v) 21W x 4
• Output frequency band 20Hz ~ 20kHz
• Preamp level 2000mV / 10kOhm,
• Preamp impedance ≤ 1400Ohm
• Speaker impedance 4Ohm ~ 8Ohm

DSP specifications

• Frequency band - front 62.5Hz ~ 16kHz
• Equalizer gain -9db ~ +9db
• 2-Way X'over / Front/Rear (HPF) / Frequency low/30/ ... /220/250Hz
• 2-Way X'over / Front/Rear (HPF) / Slope -6/-12/-18/-24 (dB/Oct.)
• 2-Way X'over / Subwoofer (LPF) / Frequency 30/40/ ...250Hz/passthrough
• 2-Way X'over / Subwoofer (LPF) / Slope -6/-12/-18/-24 (dB/oct.)
• Position: 2-Way (Front/Rear/Sub)Delay 0cm ~ 610cm (1cm step)
• Subwoofer Level -40dB ~ 6dB
• Equalizer Type Graphic
• Frequency Band 13 Bands

Video Specifications

• External Video Input Color System NTSC/PAL
• External Video Input Level (Mini Jack) 1 Vpp / 75 Ohm
• External Audio Max. Input Level (RCA) 1.5 V / 25 kOhm

Monitor Specifications

• Screen Size (Diagonal) 6.75 inches wide
• Screen Size (WxH) 151.8 x 79.7 mm
• Display System Transparent TN LCD Panel
• Drive System TFT active matrix system
• Number of pixels 1152000 pixels (800(H) x 480(V) x RGB)
• Effective pixels 99.99%
• Pixel arrangement RGB strip
• Backlight LED (Light Emitting Diode)

General specifications

• Operating voltage 14.4V (10.5 ~ 16V permitted)
• Dimensions (WxHxD) 178 x 100 x 75 mm
• Weight 1.1 gr.
• Weight, including sleeve and protective cap 1.3 kg

Accessories

• Release key 2 pieces
• Rosette Yes
• Installation sleeve Yes
• Hands-free microphone with 3 m cable
• Multilingual user manual
