DIGITAL DESIGNS  DX5x7 speakers coaxial

The D Class 5×7 Component Speaker Set consists of high tech, high fidelity drivers designed for the listener wanting to go well beyond the standard factory upgrade. Woofer: Our focus on sound quality starts with precision motor assemblies. The machined magnet gaps driven with high energy strontium magnets provide strong output from a compact design. We incorporated distortion reducing copper shorting rings for flux modulation and inductance control. The aluminum mid woofer cones achieve wide bandwidth and efficient energy transfer to the air. The compressed rubber surrounds are durable and have been optimized for light weight to increase sensitivity. Tweeter: The tweeter side of the D Class component sets is our T2a 25mm ultra-light diaphragm tweeter. This new diaphragm is less than 0.003 of an inch thick that’s almost nothing of a mm. This proprietary fabric is so thin it’s virtually see through, well, actually it is see through. The ultra-light dome is coupled to a low-distortion, neo motor with flush/surface mounting hardware and metal grill options. Crossover: The 2-way crossover features low distortion coils and metalized polypropylene caps that pass the source without degradation. The D Class components are purposefully built, enthusiast quality sets — everything you need for great sound and nothing you don’t.

-

Driver Size - in 5x7

Power Band - Watts 50-150

Impedance S4

Frequency Response - Hz 40-25kHz

dBSPL 90

Cutout Diameter - in 4.96 x 7.16

Mounting Depth - in 2.29

Shipping Weight - lbs 8
