NOMINAL SPECIFICATIONS
Nominal Diameter | 460 mm (18 in) |
Overall Diameter | 460 mm (18.11 in) |
Bolt Circle Diameter | 440 mm (17.32 in) |
Baffle Cutout Diameter | 421 mm (16.57 in) |
Depth | 201.5 mm (7.93 in) |
Flange and Gasket Thickness | 13.7 mm (0.54 in) |
Net Weight | 8.8 Kg (19.3 lb) |
Shipping Box (Single Carton Box) | 503 x 500 x 258 mm (19.8 x 19.7 x 10.2 in) |
Shipping Weight | 10.3 Kg (22.7 lb) |
TECHNICAL PARAMETERS
Nominal Impedance | 8 Ohm |
Minimum Impedance | 6.5 Ohm |
AES Power Handling (1) | 600 W |
Maximum Power Handling (2) | 1200 W |
Sensitivity (1W/1m) | 98 dB |
Frequency Range | 30÷2500 Hz |
Voice Coil Diameter | 77 mm (3 in) |
Winding Material | Cu |
Former Material | Glass Fiber |
Winding Depth | 22 mm (0.87 in) |
Magnetic Gap Depth | 10.5 mm (0.41 in) |
Flux Density | 1.2 T |
Magnet | Ferrite Ring |
Basket Material | Aluminum |
Demodulation | No |
Cone Surround (3) | Triple Roll |
NET Air Volume filled by Loudspeaker | 6.1 dm^3 (0.215 ft^3) |
Spider Profile | 1x variable height waves |
QUICK ACOUSTIC SPECS
Nominal Impedance | 8 Ohm |
Minimum Impedance | 6.5 Ohm |
AES Power Handling (1) | 600 W |
Sensitivity (1W/1m) | 98 dB |
Frequency Range | 30÷2500 Hz |
Flux Density | 1.2 T |
Magnet | Ferrite Ring |
Demodulation | No |
Cone Surround (2) | Triple Roll |
Fs | 30 Hz |
Re | 5.1 Ohm |
Qes | 0.30 |
Qms | 13.6 |
Qts | 0.29 |
Vas | 411.9 dm^3 (14.55 ft^3) |
Sd | 1207 cm^2 (187.09 in^2) |
Xmax (3) | 9.25 mm |
Xdamage (4) | 21 mm |
Mms | 139.0 g |
Bl | 21 N/A |
Le | 1.06 mH |
Mmd | 91.6 g |
Cms | 0.20 mm/N |
Rms | 1.9 Kg/s |
Eta Zero | 3.56 % |
EBP | 100 Hz |
QUICK MECHANICAL SPECS
Nominal Diameter | 460 mm (18 in) |
Overall Diameter | 460 mm (18.11 in) |
Bolt Circle Diameter | 440 mm (17.32 in) |
Baffle Cutout Diameter | 421 mm (16.57 in) |
Depth | 201.5 mm (7.93 in) |
Flange and Gasket Thickness | 13.7 mm (0.54 in) |
Net Weight | 8.8 Kg (19.3 lb) |
Shipping Box (Single Carton Box) | 503 x 500 x 258 mm (19.8 x 19.7 x 10.2 in) |
Shipping Weight | 10.3 Kg (22.7 lb) |
