Nakamichi NGTD1200.1 amplifier 1200W monoblock

.

The Nakamichi NGTD1200.1 is a high-performance monoblock amplifier designed to deliver powerful and dynamic audio performance. With a rated power of 1200W at 1 Ohm, this amplifier is perfect for driving subwoofers and providing deep, powerful bass. Its maximum power of 6000W ensures that this amplifier can handle even the most demanding sound systems without compromising performance.

The amplifier delivers 400W at 4 Ohms, 700W at 2 Ohms, and a full 1200W in bridged mode at 4 Ohms, offering great flexibility depending on the configuration of your sound system. With a frequency response between 30Hz and 80Hz, it is specifically designed to handle low-frequency sounds, providing powerful bass reproduction with high precision.

The NGTD1200.1 has an input sensitivity range of 0.15V to 8V, making it compatible with a wide range of audio sources and system setups. The fuse size is 30A x 3, providing ample protection against overcurrent and ensuring stable performance over time.

Despite its powerful output, the amplifier is relatively compact, weighing around 2.8 kg with dimensions of 339mm x 210mm x 58.5mm, making it easy to install in various types of vehicles without taking up too much space.

In summary, the Nakamichi NGTD1200.1 is the perfect solution for those seeking powerful bass and maximum output in their sound system. Its flexible output options and high maximum power make it an ideal amplifier for audio enthusiasts looking to take their system to the next level.

.

Technical data

Attribute Value

• Number of channels 1
• Amplifier class Class D
• Power in 1 ohm RMS 1200W
• Power in 2 ohms RMS 700W
• Power in 4 ohms RMS 400W
• Low pass filter Yes
• Bass boost Yes
• Bass remote / remote control Yes
• Operating voltage 11-16V
• Recommended power and ground cable 20mm2
• Fuses 3x30A
• Low level output Yes
