Cerwin Vega PH694 PRO Full Range Coaxial

Cerwin Vega PH694 is a pair of 6x9 "coaxial speakers with really good sound and performance at a full 160W RMS.

NOTE! sold in pairs = the package contains 2 speakers

Features:

• 6 x 9 ”PRO full-axis horn ax speakers
• High temp ferrite strontium magnet structure
• Heavy stamped steel basket
• Advanced design of voice coil heat sink for better heat dissipation
• 1.5 ”Single Layer High Temp Voice Coil with Black CoatedVoice Coil Former for Woofer
• 1.0 ”Single Layer High Temp Voice Coil with Black CoatedVoice Coil previously for tweets
• 12 dB second-order filter transition for better treble protection

Technical data

Model Cerwin Vega PH694
Product ID PH694
Power resistance RMS 160W
Power resistance max 320W
Frequency range 80Hz -18Khz
Sensitivity 101dB 1W / 1M
Impedance 4ohm
Size mid-bass 6x9 "
Speaker grille Optional
Mounting holes 222mm / 152mm
Installation depth 99mm
Outer diameter midbas 236mm / 164 mm
